⊙High strength aluminum alloy die casting shell,impact level can reach IK09;
⊙High-performance patent optical lens,light transmittance was95%,no glare.
⊙A full set of stainless steel fasteners,convenient installation,free maintenance;
⊙Adopted quick plug type electrical connection in the design,maintenance more convenient and safe;
|
Model |
Power |
Lm |
Input Voltage |
Power Factor |
Diameter(管径) |
IP Rating |
|
501A1 |
100W |
12000 |
85~265V,50~60Hz |
＞0.95 |
Φ60 |
IP65 |
|
501A2 |
150W |
18000 |
85~265V,50~60Hz |
＞0.95 |
Φ60 |
IP65 |
|
501B1 |
200W |
22000 |
85~265V,50~60Hz |
＞0.95 |
Φ60 |
IP65 |
|
501B2 |
250W |
28000 |
85~265V,50~60Hz |
＞0.95 |
Φ60 |
IP65 |
